LEESON 5KC39RN44X C334 / 5KC39RN44GX Fan and Blower Motor, 1 HP, 1 Phase, 60 Hz, 115/208-230V, 3600 RPM
Get it by Friday, Jun 20
€368.56 /unit
Add To Cart
Request a Quote
Payment
Get it by Friday, Jun 20
Payment
Item | Oil Burner Motor |
Bearing Type | Ball |
Body Dia. | 5.66" |
Bolt Circle Dia. | 2.938" |
Cc Number | CC003A |
Conduit Box Location | Exterior |
Conduit Box Position | F1 Only |
Duty Cycle | Continuous |
Frame | 56C |
Frequency | 60 Hz |
Full Load Amps | 13.2/6.5-6.6A |
Full Load Efficiency | 68.1% |
Includes | Shaft Slinger |
Insulation Class | Class B |
Length Less Shaft | 10.688" |
Max. Ambient Temp. | 40°C |
Motor Application | Pump |
Motor Enclosure Design | Open Dripproof |
Motor Frame Material | Steel |
Motor Mounting Position | Horizontal |
Motor Mounting Type | C Face, Footless |
Motor Shaft Design | Keyed |
Motor Shaft Rotation | CW/CCW |
Motor Sub Application | Jet Pump |
Motor Thermal Protection | Automatic |
Motor Type | Capacitor Start |
Mounting Type | Face |
Nameplate Rpm | 3450 RPM |
Number Of Speeds | 1 |
Overall Length | 12 5/8" |
Phase | 1 |
Rpm Range | 3001-3600 RPM |
Service Factor | 1.4 |
Shaft Dia. | 5/8" |
Shaft Length | 1 7/8" |
Shaft Material | Carbon Steel |
Shaft Type | Keyed |
Thermal Protection | Automatic |
Usable @ 200v | No |
Usable @ 208v | Yes |
Voltage | 115/208-230V |
Hp | 1 hp |
Hz | 60 Hz |
Ins. Class | Class B |
Motor Bearings | Ball |
Motor Design | Capacitor Start |
Motor Service Factor | 1.4 |
No. Of Speeds | 1 |
Nominal Efficiency | 68.1% |
Standards | CSA CERTIFIED, UL RECOGNIZED |
Weight | 22 lbs. |
Ship weight (kg) | 9.9 |
Ship height (cm) | 19.05 |
Ship length (cm) | 34.77 |
Ship width (cm) | 18.11 |
HS code | 8501406040 |
Country of Origin | MX |
Product | Model | Body Dia. | Enclosure | Full Load Amps | HP | kW | Motor Mounting Position | Mounting | NEMA Design | Price | |
---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
5KC49TN2141X | 6.42" | Open Dripproof | 21.2/11.5-10.6 | 2 | - | All Angle | Face | - | €621.06 | |
![]() |
5KCR48TN2142T | 6.42" | Open Dripproof | 29.4/14.7 | 3 | - | All Angle | Face | - | €987.75 | |
![]() |
5KC36JN268X | 5.625" | - | 7.6/3.8 | 1/2 | - | Horizontal | - | - | €279.04 | |
![]() |
5KC37FN71X | 5.625" | - | 6.4/3.2 | 1/3 | - | Horizontal | - | - | €254.97 | |
![]() |
056C34D2105 | - | DP | 12/6.2-6 | 1 | 0.75 | - | C-Face Footless | DEFINITE DUTY | €379.67 | |
![]() |
056S34D93 | - | DP | 5.5 | 1/3 | 0.25 | - | C-Face Footless | NO DESIGN CODE | €77.66 | RFQ
|
![]() |
056C34D2099 | - | DP | 7.4/3.5-3.7 | 1/2 | 0.37 | - | C-Face Footless | DEFINITE DUTY | €292.01 |
