Product Specifications:
| Item | Aeration Fan Motor |
| Application | Farm Duty |
| Bearing Type | Ball |
| Bolt Circle Dia. | 5 1/8" |
| Capacitor Required | Yes |
| Duty Cycle | Continuous |
| Efficiency | 71.7% |
| Frame | 56Z |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 9.8/4.9A |
| Hp | 3/4 hp |
| Length Less Shaft | 9" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Aeration Fan Motor |
| Motor Enclosure Design | Totally Enclosed Non Ventilated |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Wall Bracket |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Aeration Fan |
| Motor Thermal Protection | Automatic |
| Motor Type | Capacitor Start |
| Mounting Type | Wall Bracket |
| Nameplate Rpm | 3450 RPM |
| No. Of Speeds | 1 |
| Nominal Efficiency | 71.7% |
| Number Of Speeds | 1 |
| Overall Length | 11 1/4" |
| Phase | 1 |
| Service Factor | 1.25 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2 1/4" |
| Thermal Protection | Automatic |
| Usable @ 200v | Yes |
| Usable @ 208v | Yes |
| Voltage | 115/230V AC |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start |
| Motor Frame Material | Steel |
| Motor Service Factor | 1.25 |
| Standards | CSA CERTIFIED, UL RECOGNIZED |
| Weight | 20 lbs. |
Shipping Info:
| Ship weight (kg) | 9 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 32.08 |
| Ship width (cm) | 17.63 |
| HS code | 8501404040 |
| Country of Origin | MX |
Product Details:
- Starting Type: Switch and Mech
- KVA Code: K
- Drive End Bearing: BALL
- Opposite End Bearing: BALL
- Drive End Bearing Size: 6203
- Opposite End Bearing Size: 6203
Explore Products
- STARRETT 99906-13-02 13463 Band Saw Blade, 1 Inch Blade Width, 13 Feet 2 Inch Size, 0.035 Inch Blade Thickness
- TITAN FASTENERS XJAC5435X10
- MAKITA A-95853 Assortment Sandpaper Oscillating 10 Pcs
- GATES 723122795 Hydraulic Hose, 0.5 Inch I.D
- TB WOODS 14MPC180S90 QT Power Chain II Belt Sprocket, Cast Iron, 16.14 inch Hub Dia., 90mm Belt Width
- EATON LGH363038ZGGC Molded Case Circuit Breaker, Lg-Frame, Lg Type, Alsi Trip, 3-Pole, 630A, Line/Load
- 3M 4646 VHB Tape 6 Inch x 5 yard Dark Gray
- 80/20 25-4030 25 S Right Angle Universal Living Hinge, Straight Arms
Explore More
- KEYSHAFT
- NOBLES
- OAKLEY
- SNR
- INTEGRA
- Gas Infrared Tube Heaters
- Regenerative Blower Relief Valves
- Mounting Base
- Electrical Properties Data Loggers
- Key Switches
- Flexible Bed Spiked Shoes - TOUGH GUY
- Coil Transfer Cars - AUTOQUIP
- General Utility Work Gloves - IRONCLAD
- 37-155 Alphatec Solvex Comfortable Chemical Resistant Gloves - ANSELL
- Adapter Flange, Bronze, Press x Flange - VIEGA PROPRESS
- Blank Tag, 5-3/4"H, 2-7/8"W - ELECTROMARK
- Adjustable Shelfs - LITTLE GIANT
- SPN Series Step Poly Nestables - VESTIL
- Keys - WESTWARD
- Access Valves With Copper 90 Degree Elbows - JB INDUSTRIES
Contact us
Contact your account manager right away to get personal advice.
We're available Monday through Friday, from 07:30 until 17:00.
LEESON 5KC37NN3544T C1467 Aeration Fan Motor, 0.75 HP, 1 Phase, 60 Hz, 115/230V, 3600 RPM
